SolarGard® HP Supreme Film

SolarGard® HP Supreme Film Series.

The best-of-the-best in a hybrid film. A color-stable metal hybrid with excellent solar heat-rejecting performance.

Backed by a lifetime warranty, HP Supreme also offers superior optical clarity with one of the darkest VLTs available at 4%

See actual warranty certificate for details and coverage activation.

Specification	HPSupreme 42	HPSupreme 35	HPSupreme 30	HPSupreme 22	HPSupreme 16	HPSupreme 10	HPSupreme 4
Visible light transmittance %	44%	35%	31%	25%	17%	9%	5%
Visible light reflectance (exterior) %	10%	8%	9%	7%	6%	5%	5%
Visible light transmittance on auto glass %	37%	29%	26%	21%	14%	8%	4%
UV light blocked (300 to 380 nm) %	>99%	>99%	>99%	>99%	>99%	>99%	>99%
Total solar energy rejected %	44%	45%	49%	48%	50%	53%	55%
SIRR - Selective Infrared energy rejected %1	49%	44%	56%	51%	54%	56%	61%
IRER - Infrared energy rejected %2	44%	44%	48%	46%	45%	46%	48%

Performance results are calculated using NFRC methodology and LBNL Window software, and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and are subject to normal manufacturing variances.
Performance results based on film applied to ¼” (6mm) clear glass and a representative automotive glass with a base visible light transmission of 75%. Due to variations in glass performance, these values should not be used to comply with local tinting laws.

[1] SELECTIVE INFRARED REJECTION (SIRR) The percent of "film only" transmitted infrared energy (780 nm to 1700 nm) measured using the Solar Spectrum transmission meter (model # SS2450). The higher the number, the less infrared directly transmitted.
[2] INFRARED ENERGY REJECTION (IRER) The percent of infrared energy (780 nm to 2500 nm) that is directly reflected and absorbed and radiated outwards. Calculated as 1 – SHGC (780 nm to 2500 nm) using Lawrence Berkeley National Laboratory (LBNL) Window software and NFRC 200 solar spectrum from 780 nm to 2500 nm. The higher the number, the more infrared energy reflected and absorbed and released outwards. IRER is the endorsed calculation method of IWFA.
